Cellarator CX (E) R407C
The innovative CXE Cellarator split range is designed to help the licensed trade maintain a cooled environment more effectively than ever before.
With its revolutionary one piece moulded body, impregnated with an anti-bacterial additive, the Cellarator is ideal for cellar cooling, food preparation areas and other areas requiring controlled temperatures down to 4°C.
Provides consistent temperature control combined with economy, ease of maintenance, flexible positioning, hygiene, safety and reliability.
Specification
- Capacity range from 2.3 - 6.8kW
- Now available as a pump down option in five sizes including CXE90
- Long pipe runs up to 80m (50m for CKC/DCU+ 20 & 30)
- The unit controls temperatures down to 4°C (dependent upon system match)
- De-ice stat is standard on CXE electronic units
- Antibacterial agent added to the chassis during the moulding process for complete mold protection throughout the material
- 6 fins-per-inch brewery specification heat exchanger
- Mounting brackets suitable for both wall and ceiling mounting and a waterproof power switch
- Direct access to the electrics at the front of the unit
- ABS drain tray incorporating standard 22mm OD fitting drain stub
- Easy to install electric heater kit with factory fit option Outdoor condensing units incorporating a low pressure switch, HP switch and low ambient start as standard
- Optional ducted condensing units for where external installations are not feasible
- Stylish design chassis and rounded corners for safety
- The innovative CXE Cellarator split system is designed to help the licensed trade maintain a cooled environment more effectively than ever before
- With its revolutionary one piece moulded body, impregnated with an anti-bacterial additive, the CX(E) is ideal for cellar cooling, food preparation areas and any areas requiring controlled temperatures down to 4°C
- The Cellarator provides consistent temperature control with economy, ease of maintenance, flexible positioning, hygiene, safety and reliability
- Matched with CKC or DCU(+) condensing units, which are supplied with a nitrogen holding charge
- The CXE Low Temperature is for more challenging environments
Additional Features
- CXE 30 - 18kg CXE 40 - 18kg
- CXE 50 - 20kg CXE 70 - 23kg
- CXE 30 - 70 - 467mm x 845mm x 320mm
